Benefits of the BB-400 Compact Edge Controller

  • Combines rugged industrial features with Raspberry Pi and Arduino technology.
  • Easy Edge Processing for industrial applications.
  • Multiple I/O and connnectivity/networking features.

Brainboxes BB-400 NeuronEdge Smart Controller for Industry 4

The Brainboxes BB-400 NeuronEdge can sense, sort and send your machine data to minimise downtime and speed up response time. Combining industrial hardware connections with the processing power of a Raspberry Pi Compute Module 3+ the BB-400 NeuronEdge gives you the possibilities of open source software in a simple retrofit way, unlocking the potential of your equipment. The BB-400 NeuronEdge combines Brainboxes proven IO and serial connectivity with a range of network connections to allow data to flow to the application of your choice. The innovative design uses a Raspberry Pi Compute module and an Arduino to provide edge processing. The Raspberry Pi is supported by a power management system, making it match the robust demands of industry. This allows you to develop on Raspberry Pi and deploy seamlessly to the factory floor. The device offers the flexibility of PC systems with open source API programming options to make integration and customisation user friendly.

  • Multiple connections within compact DIN mount design.
  • Comes with easy to use web interface.
  • Edge Processing with innovative industrialised Raspberry Pi.
  • Develop on Raspberry Pi and deploy seamlessly to Industry.
  • 8 Digital IO lines.
  • Works with common 0...3 0V sensors.
  • 1 Ethernet port for wider network.
  • 1 Ethernet port for LAN network.
  • Extendable WiFi antenna.
  • Bluetooth - for wireless sensors.
  • UPS power management - prevents corruption.
  • Dual redundant 5...30 VDC power supply.
  • Raspberry Pi Compute 3+ module and Arduino processing power.
  • Edge processing sends relevant data to your application or the cloud.
  • Highly compatible open source software.
  • Customise with APIs and Docker containers, REST, Websockets, or .NET APIs.
  • Program in your favourite language such as C# and Python, or use out-of-the-box applications.

Included: BB-400, antenna, quick start guide.
