Reliable data acquisition and control. Proven PC DAQ boards for industry and lab.
MegaZoom, up to 1 GHz. Keysight InfiniiVision 3000T with touch screen. For sophisticated applications.
UltraVision II, up to 2 GHz. Rigol MSO8000 series with touch screen, mixed signal.
5G multichannel analysis test set. Ceyear-5252D for 5G NR Standards and 3GPP TS 38.14 test models - coming soon!
Siglent Measurement Instruments new at Meilhaus Electronic! Oscilloscopes, Spectrum Analyzers, Waveform Generators...
Realtime and UltraReal. Rigol spectrum analyzers with realtime/FFT up to 40 MHz and GPSA/sweeping up to 6.5 GHz in one device.
Still using a multimeter? Better use the flexible testing system for cables and harness. German MEcademy trainings for users!
With web interface and Cloud access. Measure U, I, temperature (TC, PT50/100/500/1000), strain gauge. 16 channels in 24-bit-precision.
B+K Precision Test and Measurement instruments new at Meilhaus Electronic!
Safe Connections
- Compact, light weight optical fiber fusion splicer.
- 4 or 6 motors for sconvenient, active core adjustment.
- comfortable, intuitive operation with versatile functions.
For all common optical fibers, rubber-insulated fibers and jumpers. 7 s fast fusion splicing, 18 s highy efficient heating. USB and SD-card slot. Built-in, replaceable battery.
New Products, Highlight, Recommendations
Best of Both World
Combines the benefits of real-time sampling, equivalent-time sampling and high analog bandwidth. 5 or 16 GHz bandwidth, 1 or 5 TS/s ETS.
PC-independent Cable Testing
Autonomous cable tester, can be operated without PC software with touch display. Very robust construction for productive use.
UltraVision II Oscilloscope up to 2 GHz, Touch
Rigol MSO8000 4-channel oscilloscope up to 2 GHz, 10 GS/s sample rate and 600,000 Wfms/s capture rate. MSO: Logic analyzer on board!
5G Multichannel Analysis System
Coming soon: Ceyear-5252D for 5G NR communication standards such as GSM, WCDMA, LTE base station test; all 3GPP 38.141 defined test models.
Promo MSO 4-Channel Bandwidth Upsale
Get next level bandwith 4-channel mixed signal oscilloscope/MSO at the price of lower bandwidth model. For InfiniiVision MSOX3000T; until 2020-4-31.
USB and DisplayPort up to 100 m
Extend the distance up to 100 m with standard Cat6a/7 cable. For USB 3-2-1, DisplayPort, additional Ethernet and RS232 pass-through.
Reliable Splicing of Optical Fibers
Fast and heat efficient fusion splicing of optical fibers - very compact. 4 or 6 motors for convenient, active core adjustment.
DC power for your test system
DC autoranging power supplies up to 400 W. 2-channel models with automatic internal series/paralle for more voltage/current.
Programmable DC loads up to 300 W
150 V/30 A, CC, CV, CR CP modes and versatile protection features. 4-wire sense function.
IIoT Datalogger
...for U, I, TC, PT50/100/500/1000, strain gauges. With WLAN/LAN, web interface and Cloud access.
Siglent Measurement Instruments
Oscilloscopes (new: SDS5000X up to 1 GHz), waveform generators, spectrum analyzers, multimeters, power supplies.
RF Measurement up to 67 GHz
Spectrum analyzers, RF modulation signal sources and vector network analyzers (VNA) up to 67 GHz.
Keysight Streamline Scope Series
InfiniiVision 3000 scope power now also for USB - as an embedded PC oscilloscope.
Bandwidth up to 1 GHz!
Keysight scope power: MegaZoom oscilloscopes of the InfiniiVision 3000A and T series (T with touch operation).
With UltraVision II and Touch
2/4-channel oscilloscopes up to 350 MHz, 8 GS/s sample rate, 500,000 Wfms/s capture rate. MSO: Logic analyzer on board!
Maximum Flexibility
System with 3 slots/8 module types - for multi-channel DAQ/switching. Successor of the 34970A/34972A.
Made For Reliability
DAQ and control boards, incl. Windows drivers, LabVIEW drivers, DAQ lab and skripting software ME-PowerLab3.
