eX-9530 - Converter USB to RS232, RS422, RS485

eX-9530 - Converter USB to RS232, RS422, RS485
additional images:
progressive price
taking 1 pcs
€ 84,50
taking 5 pcs
€ 81,12
taking 20 pcs
€ 77,74
taking 50 pcs
€ 74,36
taking 200 pcs
€ 70,98
Price
84,50*
€ 100,56 brutto
* excluding VAT plus shipping
Quantity:
Total
Unit price
base price
Stock:
Delivery time
Delivery Time ~2-3 weeks
Description

Benefits

  • Use serial RS232 devices at USB.
  • Control RS485/RS422 network via USB.
  • Isolation up to 3000 V.

eX-9530 - Converter from USB to RS232, RS485, RS485.

These communication modules bring serial RS232 devices or a decentral RS485 networking system to your PC, simply using USB. The modules match the eX series but can also be used with other serial systems.

  • Converter USB-to-RS232/RS422/RS485.
  • Supply power +10...+30 VDC.
  • DIN-rail mountable and wall mountable.

Model Overview

Model eX-9530
Conversion USB to RS232, RS485, RS422
USB USB 1.1
Serial COM 1 port RS232/RS422/RS485 auto switching; 300...115,200 bps; AutoPro: Auto baudrate switching; RS232 full-duplex, RTS & CTS handshaking;
RS422: full-duplex;
RS485: Auto direction flow control, transient suppression on the data lines; RS422/RS485 distance up tos 1200 m
Isolation 3000 V
Power, consumption +10...+30 VDC, 0.65 W
Connectors RS: Screw terminals, USB: Type B

Included: Module, DIN-rail and wall-mount brackets, instructions for use, driver CD, USB cable.

Accessories, options
Query on the Item?
Do you have any questions on this item? Do you want to be updated with information on availability?
Don't forget to quote your name, company and phone number, so we can quickly reach you, if there are any questions from our side!
Your E-mail Adress
Name, company, phone, your question:
Tell a friend
Description
Accessories, options
Query on the Item?
Tell a friend

Benefits

  • Use serial RS232 devices at USB.
  • Control RS485/RS422 network via USB.
  • Isolation up to 3000 V.

eX-9530 - Converter from USB to RS232, RS485, RS485.

These communication modules bring serial RS232 devices or a decentral RS485 networking system to your PC, simply using USB. The modules match the eX series but can also be used with other serial systems.

  • Converter USB-to-RS232/RS422/RS485.
  • Supply power +10...+30 VDC.
  • DIN-rail mountable and wall mountable.

Model Overview

Model eX-9530
Conversion USB to RS232, RS485, RS422
USB USB 1.1
Serial COM 1 port RS232/RS422/RS485 auto switching; 300...115,200 bps; AutoPro: Auto baudrate switching; RS232 full-duplex, RTS & CTS handshaking;
RS422: full-duplex;
RS485: Auto direction flow control, transient suppression on the data lines; RS422/RS485 distance up tos 1200 m
Isolation 3000 V
Power, consumption +10...+30 VDC, 0.65 W
Connectors RS: Screw terminals, USB: Type B

Included: Module, DIN-rail and wall-mount brackets, instructions for use, driver CD, USB cable.
