Rohde & Schwarz FPL Hardware Accessories
Model Overview
| Model | Description | ||
| FPL1-B10 | 1323.1890.02 | Additional interface for remote control by GPIB | Plug-in unit (hardware option) |
| FPL1-B19 | 1304.0427.02 | Second hard disk for FPL1000, premounted on PC board incl. analyzer firmware, for exchange against standard hard drive | Hardware option |
| FPL1-B30 | 1323.1877.02 | DC power supply for 12/24 V supply voltage | Plug-in unit (hardware option) |
| FPL1-B31 | 1323.1725.02 | Li-Ion battery pack for internal battery slot, includes charging unit, charges by 110/240 VAC or optional 12/24 VDC | Retrofittable in R&S Service (hardware option) |
| FPL1-B31 | 1323.1725.03 | Li-Ion battery pack for internal battery slot, includes charging unit, charges by 110/240 VAC or optional 12/24 VDC, for EPL1001/1007 | Retrofittable in R&S Service (hardware option) |
| FPL1-B4 | 1323.1902.02 | OCXO, precision frequency reference, aging/year: <1x10-7, temp. drift: <1x10-7 | Retrofittable in R&S Service (hardware option) |
| FPL1-B5 | 1323.1883.02 | Additional interfaces: User port, noise source control, power sensor, IF/video/demod out, AF output | Plug-in unit (hardware option) |
| FPL1-B9 | 1323.1925.03 | Internal generator 5 kHz...3 GHz for FPL1003 | Factory fitted option |
| FPL1-B9 | 1323.1925.07 | Internal generator 5 kHz...7.5 GHz for FPL1007 | Factory fitted option |
| FPL1-Z1 | 1323.1960.02 | Protective hard cover for FPL1000 | Hardware option |
| FPL1-Z2 | 1323.1977.02 | Protective hard cover for FPL1000, transparent cover | Hardware option |
| FPL1-Z3 | 1323.1683.02 | H-style shoulder harnes for FPL1000 for portable operation with optional battery pack (FPL1-Z2 required) | Hardware option |
| FPL1-Z4 | 1323.1677.02 | Spare battery pack for FPL1000; option FPL1-B31 required; battery pack consists of two single batteries | Hardware option |
| FPL1-Z6 | 1323.1954.02 | 19" rack adaptoer for FPL1000 in RAL 5014 pigeon blue | Hardware option, retrofit by user |
| FPL1-Z6B | 1323.1954.03 | 19" rack adaptor for FPL1000 in RAL 5000 violet blue | Hardware option, retrofit by user |
| FPL1-Z7 | 1353.6648.02 | Adaptor cable from the analyzer's 25-pin AUX port to the generator's BNC trigger input. Enables significantly faster measurement rates with an external generator through TTL handshake. Requires option FPL1-B5 and FPL1-B12 | Hardware option |
