Icron Ranger 2312 - USB 2.0 Extender over 100 m Cat5e/6/7, 2-Port Hub

Ranger 2312 - USB 2.0 extender over 100 m Cat5e/6/7, 2-port hub
additional images:
progressive price
taking 1 pcs
€ 342,00
taking 3 pcs
€ 324,90
Price
342,00*
€ 406,98 brutto
* excluding VAT free shipping (Germany)
Quantity:
Total
Unit price
base price
Stock:
on stock
Delivery from stock
Description

Benefits

  • Extension for USB 2.0 over Cat5e/6/7 cable.
  • Distances up to 100 m. 2-port hub.
  • Easy connectivity with two extender modules.

Icron Ranger  2312 - Extend USB 2.0 over 100 m Cat5e/6/7 Copper Cable, 2-Port Hub

These modules are used to extend the USB transmission with 100 m. The extenders are connected with commercially obtainable standard Cat5e/6/7 Ethernet cable. Integrated 2-port hub on REX side.

Model Overview

Model Ranger 2312
Ordering Code 00-00407
Series ExtremeUSB 2.0
Extender USB 2.0 up to 480 Mbps/Lowspeed and Fullspeed; compatible with USB 1.1
Distance 100 m
Ports 1 to 2
Medium Cat 5e/6/7 copper/Ethernet cable
Model 2 modules (LEX and REX)
Power supply Either the LEX or REX can use a power adapter. Only one is required
Applications Industrial control, KVM extension, digital signage, security: Web camera, access control and more
Software Transparent, no additional driver software required

LEX = Local Extender, extender module at host.
REX = Remote Extender module.

Included: LEX, REX, power supply adaptor. Cat5e/6/7 cable not included!
