LCR Elite1 - Basic LCR Meter with Tweezer Probe

LCR Elite1 basic LCR meter with tweezer probe
additional images:
progressive price
taking 1 pcs
€ 195,00
taking 3 pcs
€ 185,25
Price
195,00*
€ 232,05 brutto
* excluding VAT plus shipping
Quantity:
Total
Unit price
base price
Stock:
on stock
Delivery from stock
Description

Benefits

  • LCR meter and tweezer-style probe in one.
  • Easy to use with one navigation button only.
  • Clear OLED.

Basic Tweezer-Style LCR Meter with 0.5% Accuracy, for SMD Components.

The LCR Elite1 is a LCR meter designed to measure inductance (L), capacitance (C) and resistance (R) with high accuracy. It is small, light and super-convenient for you to carry everywhere. The gold-plated precise tips allow you to contact the SMD components easily and reliably with sizes down to 0201. The 4-wire shielded probe improves measurement accuracy and reduces parasitic parameters to a minimum. The highly integrated hardware improves the performance and reduces the size significantly, making the LCR Elite1 an ideal choice for a broad range of applications and missions, including electronics labs, QA inspection, production lines, service center, etc.

  • Precise gold-plated tips for L, C, R measurement.
  • Automatic or manual component identification.
  • Automatic or manual test frequency selection.
  • Automatic or manual circuit mode.
  • One hand operation to pick up SMD components easily. Display configurable for right or left hander use.
  • Portable design with bright OLED display.
  • Built-in rechargeable Lithium-ion polymer battery. Long battery life
  • Standard USB charging via computer or USB power adapter.

Included: LCR Elite1 portable LCR meter, storage box, quick start guide, NIST certificate.

Model Overview

Model LCR Pro1 LCR Pro1 Plus LCR Elite1 LCR Elite2
Accuracy 0.1% (R), 0.2% (C), 0.2% (L) 0.5% (R), 1.0% (C), 1.0% (L) 0.2% (R), 0.2% (C), 0.4% (L)
Test frequency 100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz 100 Hz, 1 kHz, 10 kHz 100 Hz, 120 Hz, 1 kHz, 10 kHz
Test voltage 0.2 Vrms, 0.5 Vrms, 1.0 Vrms (source impedance 100 Ω) 0.45 Vrms (source impedance 100 Ω) 0.5 Vrms (source impedance 100 Ω)
Resistance (R) yes (range 25 mΩ...10 MΩ) yes (range 20 mΩ...10 MΩ) yes (range 25 mΩ...10 MΩ) yes (range 20 mΩ...10 MΩ)
Inductance (L) yes (range 10 nH...1 H) yes (range 1 nH...1 H) yes (range 100 nH...1 H) yes (range 0.1 pF...5 mF)
Capacitance (C) yes (range 0.25 pF...1 mF) yes (range 0.2 pF...10 mF) yes (range 0.3 pF...500 µF) yes (range 0.1 µH...1 H)
Impedance (Z) yes - -
Dissipation factor (D) yes - yes
Quality factor (Q) yes - yes
Phase angle (T) yes - -
Equivalent series resistance (ESR) yes yes yes
Direct current resistance (DCR) yes - -
Diode check yes - -
LED testing - yes - -
Continuity yes - -
Sorting yes - -
Recording yes - -
Self calibration yes - yes
Protection - - Aegis Technology, over voltage protection (between test tips) up to ±48 VDC (or ±34 VAC); automatically disconnects overvoltage from the meter and shows "OVER VOLT" message
PC connectivity yes (optional LCR Link1 required) - -
Dimensions (LxWxH, mm) 151 x 19 x 15, 30 g 151 x 19 x 14.5, 30 g
Display OLED 24.4 mm/0.96", 128 x 64 resolution OLED 23.1 mm/0.91", 128 x 32 resolution
Battery 3.7 V LiPO, rechargeable, 150 mAh 3.7 V LiPO, rechargeable, 180 mAh 3.7 V LiPO, rechargeable, 150 mAh 3.7 V LiPO, rechargeable, 180 mAh
External power source DC 5 V, micro-B USB connector DC 5 V, micro-B USB connector
SMD test probe Ultra-precise gold plated Precise gold plated
