HIOKI is a manufacturer of innovative and high-quality devices for current sensing, power analysis and battery measurement technology. The product range includes battery testers and battery simulators, power analyzers and the matching current probes/sensors. In addition, HIOKI offers data loggers, devices for impedance analysis, R-, C- and LCR-meters as well as memory recorders.


Battery Testing for the Technologies of Today

Batteries play a central role in current technology. Whether in e-mobility, modern communications or the IoT, batteries are hugely important because they secure the power supply for these devices. In development, industrial production to everyday use in critical areas, batteries need to be measured, characterized, tested and monitored.

HIOKI has therefore placed one of its product focuses in the area of highly reliable an accurate battery testing. Thanks to devices from HIOKI, for example, battery diagnosis times can be reduced by about 60% with the required high accuracy. HIOKI devices help to test lithium-ion batteries: Test of insulation resistance, OCV/open circuit voltage, or internal resistance, and more.


HIOKI linecard


Power Analysis for Efficient, Safe Energy Supplies

Efficiency, safety and the quality of energy supply play an enormously important role today in a time when sustainability and economy in energy consumption are essential. The power of an electrical system is the product of voltage and current (P=U*I). However, it is not quite as simple as in DC systems in practice, because here usually one has to deal with and analyze AC quantities, often even in complex multiphase systems, etc. Power analyzers are used here, which can measure or determine many other parameters in addition to voltage, current and power, including, for example, apparent and reactive power, phase angle, ripple factors and even harmonics.

Comparison HIOKI Power Analyzers Main Units

Model ▸PW8001+U7005 ▸PW8001+U7001 ▸PW6001 ▸PW3390
Applications Measurement of SiC and GaN inverters and reactor/transformer loss Measurement of high-efficiency IGBT inverters and solar inverters Measurement of high-efficiency IGBT inverters Balance of high accuracy and portability
Measurement parameters
Measurement frequency band DC, 0.1 Hz...5 MHz DC, 0.1 Hz...1 MHz DC, 0.1 Hz...2 MHz DC, 0.5 Hz...200 kHz
Basic accuracy for 50/60 Hz power ±(0.01% of reading + 0.02% of range) ±(0.02% of reading + 0.05% of range) ±(0.02% of reading + 0.03% of range) ±(0.04% of reading + 0.05% of range)
Accuracy for DC power ±(0.02% of reading + 0.03% of range) ±(0.02% of reading + 0.05% of range) ±(0.02% of reading + 0.05% of range) ±(0.05% of reading + 0.07% of range)
Accuracy for 10 kHz power ±(0.05% of reading + 0.05% of range) ±(0.2% of reading + 0.05% of range) ±(0.15% of reading + 0.1% of range) ±(0.2% of reading + 0.1% of range)
Accuracy for 50 kHz power ±(0.15% of reading + 0.05% of range) ±(0.4% of reading + 0.1% of range) ±(0.15% of reading + 0.1% of range) ±(0.4% of reading + 0.3% of range)
Number of power measurement channels 1 to 8 channels with U7001 and/or U7005 1 to 6 channels 4 channels
Voltage, current ADC sampling 18 bit, 15 MHz 16 bit, 2.5 MHz 18 bit, 5 MHz 16 bit, 500 kHz
Voltage range 6/15/30/60/150/300/600/1500 V 6/15/30/60/150/300/600/1500 V 15/30/60/150/300/600/1500 V
Current range 100 mA...2000 A (6 ranges, based on sensor) Probe 1: 100 mA...2000 A (6 ranges, based on sensor);
probe 2: 100/200/500 mV/1/2/5 V
Probe 1: 100 mA...2000 A (6 ranges, based on sensor);
probe 2: 100/200/500 mV/1/2/5 V
100 mA...8000 A (6 ranges, based on sensor)
Common-mode voltage rejection ratio 50/60 Hz: 120 dB or greater;
100 kHz: 110 dB or greater
50/60 Hz: 100 dB or greater;
100 kHz: 80 dB typ.
50/60 Hz: 100 dB or greater;
100 kHz: 80 dB typ.
50/60 Hz: 80 dB or greater
Temperature coefficient 0.01%/°C 0.01%/°C 0.01%/°C
Voltage input method Photoisolated input,resistor voltage division Isolated input, resistor voltage division Photoisolated input, resistor voltage division Isolated input, resistor voltage division
Current input method Isolated input from current sensor Isolated input from current sensor Isolated input from current sensor
External current sensor input Yes (ME15W) Yes (ME15W, BNC) Yes (ME15W, BNC) Yes (ME15W)
Power supplied to external current sensor Yes Yes Yes
Data update rate 10/50/200 ms 10/50/200 ms 50 ms
Voltage input
Maximum input voltage 1000 V, ±2000 Vpeak 1000 VAC, 1500 VDC, ±2000 Vpeak 1000 V, ±2000 Vpeak (10 ms) 1500 V, ±2000 Vpeak
Maximum rated line-to-ground voltage 600 V CAT III
1000 V CAT II
600 VAC/1000 VDC CAT III
1000 VAC/1500 VDC CAT II
600 V CAT III
1000 V CAT II
600 V CAT III
1000 V CAT II
Analysis
Number of motor analysis channels Maximum 4 motors (option) Maximum 2 motors (option) Maximum 1 motor (option)
Motor analysis input format Analog DC, frequency, pulse Analog DC, frequency, pulse Analog DC, frequency, pulse
Function
Current sensor phase shift calculation Yes (auto) Yes Yes
Harmonics measurement Yes (8, for each channel) Yes (6, for each channel) Yes
Maximum harmonics analysis order 500th 100th 100th
Harmonics synchronization frequency range 0.1 Hz...1.5 MHz 0.1 Hz...1 MHz 0.1 Hz...300 kHz 0.5 Hz...5 kHz
IEC harmonics measurement Yes Yes -
IEC flicker measurement Yes - -
FFT spectrum analysis Yes (DC...4 MHz) Yes (DC...1 MHz) Yes (DC...2 MHz) Yes (DC...200 kHz)
User-defined calculations Yes Yes -
Delta conversion Yes (Δ-Y, Y-Δ) Yes (Δ-Y, Y-Δ) Yes (Δ-Y)
D/A output Yes (option) 20 channels (waveform output, analog output) Yes (option) 20 channels (waveform output, analog output) Yes (option) 16 channels (waveform output, analog output)
General
Display 10.1"/25,7 cm WVGA TFT color LCD, touch screen 9"/22.9 cm WVGA TFT color LCD, touch screen 9"/22.9 cm WVGA TFT color LCD
Interfaces USB 2.0 (ext. storage medium), LAN (100BASE-TX, 1000BASE-T), GPIB, RS232C (max. 230,400 bps), optical link (option), CAN or CAN FD (option) USB 2.0 (ext. storage medium), LAN (100BASE-TX, 1000BASE-T), GPIB, RS232C (max. 230,400 bps), optical link USB 2.0 and CF card (ext. storage medium), LAN (10BASE-T, 100BASE-TX), RS232C (max. 38,400 bps)
External control Yes Yes Yes
Synchronization of multiple instruments Yes (up to 4 instruments) - Yes (up to 8 instruments)
Dimensions (mm) 430 x 221 x 361; 14 kg 430 x 177 x 450; 14 kg 340 x 170 x 156; 4.6 kg
